CCG Armortex EExd I / IIC Cable Gland MAC - Multi Armour Cone For use in hazardous areas

Navigate to: CCG Home | CCG Hazardous Area Cable Glands
Underground and Surface Use Group I and IIC armoured
CCG-Armortex-EExd-I-IIC-Cable-Gland

CCG Armortex EExd I / IIC Cable Gland MAC - Multi Armour Cone For use in hazardous areas.

Features and Benefits

• Nickel plated brass / stainless steel gland for steel wire, tape, braided, aluminium, armoured cable
• No need to change seals or reverse cones or cone rings to accommodate different types of armoured cable.
• Captive cone and cone ring ensures no loose parts during assembly.
• Extra long captive explosion proof seal ensures built in safety.
• Armour clamp components can be inspected after installation.
• Gland can be used on Exd enclosures greater than 2 litres volume.



CCG reserves the right to make alterations to the technical data, dimensions, designs and products available without notice. The illustrations cannot be considered binding. Please contact CGG for assistance.

Technical Data
Type - ARMORTEX
Gland Material - Brass (Nickel Plated), Stainless Steel
Seal Material - Thermoplastic Elastomer
Cable Type - Steel Wire, Braid, Tape Armour
Armour Clamping - Multi Armour Cone and Cone Ring
Sealing Area - Inner and outer sheath
Optional Accessories and Tools - Shroud, Earth Tag, Adaptor / Reducer

Download Data Sheet
