CCG BW Captive Component Cable Gland for Steel Wire Armoured Cable For indoor use
Navigate to:
CCG Home |
CCG Industrial/Mining Cable Glands
|
CCG Armoured Cable
Glands |
CCG BW Captive Component Cable
Gland for Steel Wire Armoured
Cable -
For indoor use
Features and Benefits
• For indoor use.
• Two piece handling, no loose
parts.
• Freely rotating captive cone,
providing an armour clamp and
earth bond without
twisting the steel wire
armouring.
• Adjustable bush for use with
thick gland plates.
• By removing the outer nut and
bushes the inners of sizes 1 to
3 can be used as
metric reducers.
• Precision manufactured from
high quality brass and nickel
plated.
• Complete with high quality
brass locknuts.
• Also available in aluminium on
request.
CCG reserves the right to make
alterations to the technical
data, dimensions, designs and
products available without
notice. The illustrations cannot
be considered binding. Please
contact CGG for assistance.
Technical Data
Type - BW
Gland Material - Brass (Nickel
Plated), Aluminium
Cable Type - Steel Wire Armour /
Aluminium Armour Wire
Armour Clamping - Captive
Rotating Cone
Optional Accessories - Locknut,
Shroud, Earth Tag, Adaptor /
Reducer
Download Data Sheet |
|
