CCG Ex Corrosion Guard EExde IIC MAC - Multi Armour Cone For use in highly corrosive and wet environments

Navigate to: CCG Home | CCG Hazardous Area Cable Glands
Surface Use Group IIC armoured
CCG Ex Corrosion Guard EExde IIC MAC - Multi Armour Cone For use in highly corrosive and wet environments

CCG Ex Corrosion Guard EExde IIC MAC - Multi Armour Cone For use in highly corrosive and wet environments.

Features and Benefits

• For use in highly corrosive and wet locations.
• Cable gland manufactured from high quality brass and nickel plated.
• Factory fitted captive elastomeric seals for built-in safety.
• The screw-on Corrosion Guard is manufactured from non-corrosive material to protect the steelwire armour and metal parts of the gland.
• Corrosion Guard screws onto the gland body and seals over the outer sheath of the cable giving an IP 68 seal.
• Complete with a polypropylene gasket.





CCG reserves the right to make alterations to the technical data, dimensions, designs and products available without notice. The illustrations cannot be considered binding. Please contact CGG for assistance.

Technical Data
Type - EX Corrosion Guard
Gland Material - Brass (Nickel Plated)
Corrosion Guard Material - Glass Reinforced Polyester Compound/PBT
Seal Material - Thermoplastic Elastomer
Cable Type - Steel Wire, Braid, Tape Armour
Armour Clamping - Multi Armour Cone and Cone Ring
Sealing Area - Inner & outer sheath & total enclosure of gland
Optional Accessories - Locknut

Download Data Sheet
